M05 Zemine Monte Manyetik Kapı Tutucu

KAPI DONANIMI

M05 Floor Mounted Magnetic Door Holder

Marka: DOORMARKET

3.490,00 TL

KDV dâhil

Out of stock
✓
Delivery information

Estimated dispatch for stocked products is 3–5 business days. Please confirm the product dimensions and door compatibility before ordering.

  • ✓ Product selection suited to your door dimensions
  • ✓ Installation and use support
  • ✓ International delivery options
Get Technical Support on WhatsApp For dimensions, product selection and installation support
🔒 Secure payment 🚚 Secure delivery ☎ Technical support
Ürün Açıklaması +

The M05 floor-mounted magnetic door holder is designed to hold suitable self-closing doors in the open position during normal use. It releases the door when the alarm sounds or in the event of a power failure, allowing the door closer to close the door.

Floor mounting provides a neat application in hospitals, schools, hotels, offices, and commercial buildings where the wall surface is unsuitable.

Öne Çıkan Özellikler +
• Floor-mounted compact design
• Door release upon power failure
• For use with door closers
• Integration with fire and access control systems
• Includes standard mounting hardware
Teknik Özellikler +
Mounting type: Floor mounted
Operating principle: Hold when energized, release when power is cut
Power supply: 12 V DC or 24 V DC
Operating current: 120 mA at 12 V DC; 60 mA at 24 V DC
Approximate holding force: 50 kgf
Approximate weight: 0.85 kg
Body dimensions: 70 × 45 × 100 mm
Application: Suitable self-closing doors
Malzeme ve Yapı +
It consists of a black-coated metal body, an electromagnet mechanism, and a metal strike plate applied to the door. The mounting components are suitable for solid ground applications.
Uyumluluk ve Seçim Rehberi +
The ground structure, installation distance, angle at which the door will remain open, door closer, supply voltage, and alarm or access control connection should be checked before application.
Paket İçeriği ve Aksesuarlar +
Magnetic holder body, door strike plate and standard mounting accessories are included. Project-specific cabling, power supply, and control panel are not included in the product package.
Montaj ve Kullanım +
The strength of the mounting surface and the position of the mating part must be checked. The product body should be mounted to the floor, and the mating part to the door, on the same axis. Electrical connection must be made by qualified personnel. After installation, normal operation, power outage, and alarm scenarios (if any) must be tested.
